kcc5
Class KCC_BubblesTrap

Object
  common:Generic
      common:TrapShape
          kcc5:KCC_BubblesTrap

class
TrapShape:KCC_BubblesTrap

The Bubbles trap.

For an example of what this trap looks like, click here.

Ultra Fractal Source

Toggle UF Source Code Display

 class KCC_BubblesTrap( common.ulb:TrapShape ) {
 ; The Bubbles trap.
 ; <p>
 ; For an example of what this trap looks like,
 ; <a href="../additional/kcc5/images/Bubbles Trap.jpg">click here</a>.
 ;
 public:
   import "common.ulb"

   ; constructor
   func KCC_BubblesTrap( Generic pparent )
     TrapShape.TrapShape( pparent )
   endfunc

   ; call this before each sequence of values to be trapped
   func Init( complex pz )
     TrapShape.Init( pz )

     minZ = 1.0e20
     savedRange = 0
   endfunc

   ; call this for each iteration being trapped
   float func Iterate( complex pz )
     TrapShape.Iterate( pz )

     ;****************************************************
     ; Save the smallest value of sqrt(|z|).
     ;****************************************************
     temp = sqrt( |pz| )
     if( temp < minZ )
       minZ = temp

       savedRange = m_Iterations
     endif

     ;****************************************************
     ; If the orbit point exceeds the maximum value, set z to
     ; the index into the colormap and set the bailout flag.
     ;****************************************************
     if( |pz| > @maxZ )
       if( minZ < @bubbleSize )
         m_LastChannel = savedRange
         m_Texture = minZ / @bubbleSize
         return minZ
       endif
     endif

 ;    m_LastChannel = m_Iterations

     return 1e20
   endfunc

   float func GetTextureValue()
     return m_Texture
   endfunc

 protected:
   float temp
   float minZ
   int savedRange
   float m_Texture

 default:
   title = "Bubbles Trap"

   int param v_KCC_BubblesTrap
     caption = "Version (KCC_BubblesTrap)"
     default = 100
     hint = "This version parameter is used to detect when a change has been \
             made to the formula that is incompatible with the previous version. \
             When that happens, this field will reflect the old version number to \
             alert you to the fact that an alternate rendering is being used."
     visible = @v_KCC_BubblesTrap < 100
   endparam

   float param bubbleSize
     caption = "Bubble Size"
     default = 0.1
     hint = "The size of the bubbles.  Suggested range (0.1 to 0.3)."
   endparam

   float param maxZ
     caption = "Maximum Z"
     default = 4.0
     hint = "The maximum size of the bubbles."
     visible = false
   endparam
 }


Constructor Summary

KCC_BubblesTrap()

KCC_BubblesTrap(Generic pparent)
constructor

Method Summary

float	GetTextureValue() Get texture value.
void	Init(complex pz) call this before each sequence of values to be trapped
float	Iterate(complex pz) call this for each iteration being trapped

Methods inherited from class common:TrapShape

GetColorChannel, GetTransformedPoint, IterateSilent, SetThreshold

Methods inherited from class common:Generic

GetParent

Methods inherited from class Object

Constructor Detail

KCC_BubblesTrap

public KCC_BubblesTrap(Generic pparent)

constructor

KCC_BubblesTrap

public KCC_BubblesTrap()

Method Detail

Init

public void Init(complex pz)

call this before each sequence of values to be trapped

Overrides:

Init in class TrapShape

Iterate

public float Iterate(complex pz)

call this for each iteration being trapped

Overrides:

Iterate in class TrapShape

GetTextureValue

public float GetTextureValue()

Description copied from class: TrapShape

Get texture value.

Ordinarily, a trap shape does not have a native texture (it is flat). Some formulas may pair trap shapes with trap textures, and may need more information about trap textures when trap shapes are nested via TrapShapeMerge. This function provides support for accessing texture information.

Overrides:

GetTextureValue in class TrapShape

Returns:

the texture value for the last point used (i.e. call GetTextureValue() after calling Iterate(), not before)
