kcc5
Class KCC_SquaresTrap

Object
  common:Generic
      common:TrapShape
          kcc5:KCC_SquaresTrap

class
TrapShape:KCC_SquaresTrap

The Squares trap.

For an example of what this trap looks like, click here.

Ultra Fractal Source

Toggle UF Source Code Display

 class KCC_SquaresTrap( common.ulb:TrapShape ) {
 ; The Squares trap.
 ; <p>
 ; For an example of what this trap looks like,
 ; <a href="../additional/kcc5/images/Squares Trap.jpg">click here</a>.
 ;
 public:
   import "common.ulb"

   ; constructor
   func KCC_SquaresTrap( Generic pparent )
     TrapShape.TrapShape( pparent )
   endfunc

   ; call this before each sequence of values to be trapped
   func Init( complex pz )
     TrapShape.Init( pz )

     Px = 0.5 + @squareSize
     Py = 0.5 - @squareSize
   endfunc

   ; call this for each iteration being trapped
   float func Iterate( complex pz )
     TrapShape.Iterate( pz )

     Xabs = abs( real( pz ) - real( @squaresOffset ) )
     Yabs = abs( imag( pz ) - imag( @squaresOffset ) )

     if( (Xabs < Px) && (Xabs > Py) && (Yabs < Px) && (Yabs > Py) )

       float awr5 = abs( Xabs - 0.5 )
       float awi5 = abs( Yabs - 0.5 )

       if( awr5 <= awi5 )
         distance = awr5
       else
         distance = awi5
       endif

       if( distance < @squareSize )
         m_LastChannel = m_Iterations
         m_Texture = distance / @squareSize
         return distance
       else
         return 1e20
       endif
     else
       return 1e20
     endif
   endfunc

   float func GetTextureValue()
     return m_Texture
   endfunc

 protected:
   float distance
   float Xabs
   float Yabs
   float Px
   float Py
   float m_Texture

 default:
   title = "Squares Trap"

   int param v_KCC_SquaresTrap
     caption = "Version (KCC_SquaresTrap)"
     default = 100
     hint = "This version parameter is used to detect when a change has been \
             made to the formula that is incompatible with the previous version. \
             When that happens, this field will reflect the old version number to \
             alert you to the fact that an alternate rendering is being used."
     visible = @v_KCC_SquaresTrap < 100
   endparam

   float param squareSize
     caption = "Square Size"
     default = 0.1
     hint = "The size of the squares.  Suggested range (0.02 to 0.3)."
   endparam

   complex param squaresOffset
     caption = "Offset"
     default = (0.0,0.0)
     hint = "Offset for the center of the Squares."
   endparam
 }


Constructor Summary

KCC_SquaresTrap()

KCC_SquaresTrap(Generic pparent)
constructor

Method Summary

float	GetTextureValue() Get texture value.
void	Init(complex pz) call this before each sequence of values to be trapped
float	Iterate(complex pz) call this for each iteration being trapped

Methods inherited from class common:TrapShape

GetColorChannel, GetTransformedPoint, IterateSilent, SetThreshold

Methods inherited from class common:Generic

GetParent

Methods inherited from class Object

Constructor Detail

KCC_SquaresTrap

public KCC_SquaresTrap(Generic pparent)

constructor

KCC_SquaresTrap

public KCC_SquaresTrap()

Method Detail

Init

public void Init(complex pz)

call this before each sequence of values to be trapped

Overrides:

Init in class TrapShape

Iterate

public float Iterate(complex pz)

call this for each iteration being trapped

Overrides:

Iterate in class TrapShape

GetTextureValue

public float GetTextureValue()

Description copied from class: TrapShape

Get texture value.

Ordinarily, a trap shape does not have a native texture (it is flat). Some formulas may pair trap shapes with trap textures, and may need more information about trap textures when trap shapes are nested via TrapShapeMerge. This function provides support for accessing texture information.

Overrides:

GetTextureValue in class TrapShape

Returns:

the texture value for the last point used (i.e. call GetTextureValue() after calling Iterate(), not before)
