kcc5
Class KCC_StarOfDavidTrap

Object
  common:Generic
      common:TrapShape
          kcc5:KCC_StarOfDavidTrap

class
TrapShape:KCC_StarOfDavidTrap

The Star of David trap.

For an example of what this trap looks like, click here.

Ultra Fractal Source

Toggle UF Source Code Display

 class KCC_StarOfDavidTrap( common.ulb:TrapShape ) {
 ; The Star of David trap.
 ; <p>
 ; For an example of what this trap looks like,
 ; <a href="../additional/kcc5/images/Star of David Trap.jpg">click here</a>.
 ;
 public:
   import "common.ulb"

   ; constructor
   func KCC_StarOfDavidTrap( Generic pparent )
     TrapShape.TrapShape( pparent )
   endfunc

   ; call this before each sequence of values to be trapped
   func Init( complex pz )
     TrapShape.Init( pz )

     rangeNum = 0
     halfside = 1.73205080756888 * @starSize
   endfunc

   ; call this for each iteration being trapped
   float func Iterate( complex pz )
     TrapShape.Iterate( pz )

     trapped = false

     ;Compute all the distances
     rz = real( pz )
     iz = imag( pz )
     d2 = abs( iz + @starSize )
     d4 = abs( iz - @starSize )
     d1 = abs(  0.866025403784439 * rz + 0.5 * iz - @starSize )
     d3 = abs( -0.866025403784439 * rz + 0.5 * iz - @starSize )
     d5 = abs(  0.866025403784439 * rz - 0.5 * iz - @starSize )
     d6 = abs( -0.866025403784439 * rz - 0.5 * iz - @starSize )
     ;Check line 1
     if( d1 < @starWidth )
       rangeNum = 0
       if( d2 < @starWidth )
         trapped = true
         if( d1 <= d2 )
           dist = d1
           if( iz <= -@starSize )
             dist = d2
           endif
         else
           dist = d2
           if( rz >= halfside )
             dist = d1
           endif
         endif
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       elseif( d3 < @starWidth )
         trapped = true
         if( d1 <= d3 )
           dist = d1
           if( rz <= 0.0 )
             dist = d3
           endif
         else
           dist = d3
           if( rz > 0.0 )
             dist = d1
           endif
         endif
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       elseif( d4 < @starWidth )
         trapped = true
         if( d1 <= d4 )
           dist = d1
         else
           dist = d4
           rangeNum = 1
         endif
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       elseif( d5 < @starWidth )
         trapped = true
         if( d1 <= d5 )
           dist = d1
         else
           dist = d5
           rangeNum = 1
         endif
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       elseif( rz >= 0.0 && iz >= -@starSize )
         trapped = true
         dist = d1
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       endif
     endif

     ;Check line 2
     if( d2 < @starWidth && !trapped )
       rangeNum = 0
       if( d3 < @starWidth )
         trapped = true
         if( d2 <= d3 )
           dist = d2
           if( rz <= -halfside )
             dist = d3
           endif
         else
           dist = d3
           if( iz <= -@starSize )
             dist = d2
           endif
         endif
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       elseif( d5 < @starWidth )
         trapped = true
         if( d2 <= d5 )
           dist = d2
         else
           dist = d5
           rangeNum = 1
         endif
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       elseif( d6 < @starWidth )
         trapped = true
         if( d2 <= d6 )
           dist = d2
         else
           dist = d6
           rangeNum = 1
         endif
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       elseif( abs(rz) <= halfside )
         trapped = true
         dist = d2
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       endif
     endif

     ;Check line 3
     if( d3 < @starWidth && !trapped )
       rangeNum = 0
       if( d4 < @starWidth )
         trapped = true
         if( d3 <= d4 )
           dist = d3
         else
           dist = d4
           rangeNum = 1
         endif
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       elseif( d6 < @starWidth )
         trapped = true
         if( d3 <= d6 )
           dist = d3
         else
           dist = d6
           rangeNum = 1
         endif
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       elseif( rz <= 0.0 && iz >= -@starSize )
         trapped = true
         dist = d3
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       endif
     endif

     ;Check line 4
     if( d4 < @starWidth && !trapped )
       rangeNum = 1
       if( d5 < @starWidth )
         trapped = true
         if( d4 <= d5 )
           dist = d4
           if( rz >= halfside )
             dist = d5
           endif
         else
           dist = d5
           if( iz >= @starSize )
             dist = d4
           endif
         endif
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       elseif( d6 < @starWidth )
         trapped = true
         if( d4 <= d6 )
           dist = d4
           if( rz <= -halfside )
             dist = d6
           endif
         else
           dist = d6
           if( iz >= @starSize )
             dist = d4
           endif
         endif
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       elseif( abs(rz) <= halfside )
         trapped = true
         dist = d4
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       endif
     endif

     ;Check line 5
     if( d5 < @starWidth && !trapped )
       rangeNum = 1
       if( d6 < @starWidth )
         trapped = true
         if( d5 <= d6 )
           dist = d5
           if( rz <= 0.0 )
             dist = d6
           endif
         else
           dist = d6
           if( rz > 0.0 )
             dist = d5
           endif
         endif
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       elseif( rz >= 0.0 && iz <= @starSize )
         trapped = true
         dist = d5
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       endif
     endif

     ;Check line 6
     if( d6 < @starWidth )
       rangeNum = 1
       if( rz <= 0.0 && iz <= @starSize )
         trapped = true
         dist = d6
         m_LastChannel = m_Iterations + rangeNum
         m_Texture = dist / @starWidth
         return dist
       endif
     endif

     return 1e20
   endfunc

   float func GetTextureValue()
     return m_Texture
   endfunc

 protected:
   bool trapped
   int rangeNum
   float halfside
   float rz
   float iz
   float dist
   float d1
   float d2
   float d3
   float d4
   float d5
   float d6
   float m_Texture

 default:
   title = "Star of David Trap"

   int param v_KCC_StarOfDavidTrap
     caption = "Version (KCC_StarOfDavidTrap)"
     default = 100
     hint = "This version parameter is used to detect when a change has been \
             made to the formula that is incompatible with the previous version. \
             When that happens, this field will reflect the old version number to \
             alert you to the fact that an alternate rendering is being used."
     visible = @v_KCC_StarOfDavidTrap < 100
   endparam

   float param starSize
     caption = "Star Size"
     default = 0.1
     hint = "The Size of the star.  Suggested range (0.05 to 1.0)."
   endparam

   float param starWidth
     caption = "Star Width"
     default = 0.1
     hint = "The width of the star.  Suggested range (0.01 to 0.5)."
   endparam
 }


Constructor Summary

KCC_StarOfDavidTrap()

KCC_StarOfDavidTrap(Generic pparent)
constructor

Method Summary

float	GetTextureValue() Get texture value.
void	Init(complex pz) call this before each sequence of values to be trapped
float	Iterate(complex pz) call this for each iteration being trapped

Methods inherited from class common:TrapShape

GetColorChannel, GetTransformedPoint, IterateSilent, SetThreshold

Methods inherited from class common:Generic

GetParent

Methods inherited from class Object

Constructor Detail

KCC_StarOfDavidTrap

public KCC_StarOfDavidTrap(Generic pparent)

constructor

KCC_StarOfDavidTrap

public KCC_StarOfDavidTrap()

Method Detail

Init

public void Init(complex pz)

call this before each sequence of values to be trapped

Overrides:

Init in class TrapShape

Iterate

public float Iterate(complex pz)

call this for each iteration being trapped

Overrides:

Iterate in class TrapShape

GetTextureValue

public float GetTextureValue()

Description copied from class: TrapShape

Get texture value.

Ordinarily, a trap shape does not have a native texture (it is flat). Some formulas may pair trap shapes with trap textures, and may need more information about trap textures when trap shapes are nested via TrapShapeMerge. This function provides support for accessing texture information.

Overrides:

GetTextureValue in class TrapShape

Returns:

the texture value for the last point used (i.e. call GetTextureValue() after calling Iterate(), not before)
