kcc5
Class KCC_TwoEllipsesTrap

Object
  common:Generic
      common:TrapShape
          kcc5:KCC_TwoEllipsesTrap

class
TrapShape:KCC_TwoEllipsesTrap

The Two Ellipses trap.

For an example of what this trap looks like, click here.

Ultra Fractal Source

Toggle UF Source Code Display

 class KCC_TwoEllipsesTrap( common.ulb:TrapShape ) {
 ; The Two Ellipses trap.
 ; <p>
 ; For an example of what this trap looks like,
 ; <a href="../additional/kcc5/images/Two Ellipses Trap.jpg">click here</a>.
 ;
 public:
   import "common.ulb"

   ; constructor
   func KCC_TwoEllipsesTrap( Generic pparent )
     TrapShape.TrapShape( pparent )
   endfunc

   ; call this before each sequence of values to be trapped
   func Init( complex pz )
     TrapShape.Init( pz )
   endfunc

   ; call this for each iteration being trapped
   float func Iterate( complex pz )
     TrapShape.Iterate( pz )

     angle = atan( imag( pz ) / real( pz ) )
     ellipse1 = @majorAxis1 * cos( angle ) + (0.0,0.0) * @minorAxis1 * sin( angle )
     ellipse2 = @minorAxis2 * cos( angle ) + (0.0,0.0) * @majorAxis2 * sin( angle )
     distance1 = abs( cabs( pz ) - cabs( ellipse1 ) )
     distance2 = abs( cabs( pz ) - cabs( ellipse2 ) )

     if( distance1 < distance2 )
       segment  = 0
       distance = distance1
     else
       segment  = 1
       distance = distance2
     endif

     if( distance < @ellipseWidth )
       m_LastChannel = m_Iterations + segment
       m_Texture = distance / @ellipseWidth
       return distance
     endif

     return 1e20
   endfunc

   float func GetTextureValue()
     return m_Texture
   endfunc

 protected:
   int segment
   float angle
   complex ellipse1
   complex ellipse2
   float distance
   float distance1
   float distance2
   float m_Texture

 default:
   title = "Two Ellipses Trap"

   int param v_KCC_TwoEllipsesTrap
     caption = "Version (KCC_TwoEllipsesTrap)"
     default = 100
     hint = "This version parameter is used to detect when a change has been \
             made to the formula that is incompatible with the previous version. \
             When that happens, this field will reflect the old version number to \
             alert you to the fact that an alternate rendering is being used."
     visible = @v_KCC_TwoEllipsesTrap < 100
   endparam

   float param ellipseWidth
     caption = "Elipse Width"
     default = 0.1
     hint = "The width of the ellipses."
   endparam

   float param majorAxis1
     caption = "Ellipse 1 Major Axis"
     default = 0.6
     hint = "The major axis length of ellipse 1."
   endparam

   float param minorAxis1
     caption = "Ellipse 1 Minor Axis"
     default = 0.6
     hint = "The minor axis length of ellipse 1."
   endparam

   float param majorAxis2
     caption = "Ellipse 2 Major Axis"
     default = 0.2
     hint = "The major axis length of ellipse 2."
   endparam

   float param minorAxis2
     caption = "Ellipse 2 Minor Axis"
     default = 0.2
     hint = "The minor axis length of ellipse 2."
   endparam
 }


Constructor Summary

KCC_TwoEllipsesTrap()

KCC_TwoEllipsesTrap(Generic pparent)
constructor

Method Summary

float	GetTextureValue() Get texture value.
void	Init(complex pz) call this before each sequence of values to be trapped
float	Iterate(complex pz) call this for each iteration being trapped

Methods inherited from class common:TrapShape

GetColorChannel, GetTransformedPoint, IterateSilent, SetThreshold

Methods inherited from class common:Generic

GetParent

Methods inherited from class Object

Constructor Detail

KCC_TwoEllipsesTrap

public KCC_TwoEllipsesTrap(Generic pparent)

constructor

KCC_TwoEllipsesTrap

public KCC_TwoEllipsesTrap()

Method Detail

Init

public void Init(complex pz)

call this before each sequence of values to be trapped

Overrides:

Init in class TrapShape

Iterate

public float Iterate(complex pz)

call this for each iteration being trapped

Overrides:

Iterate in class TrapShape

GetTextureValue

public float GetTextureValue()

Description copied from class: TrapShape

Get texture value.

Ordinarily, a trap shape does not have a native texture (it is flat). Some formulas may pair trap shapes with trap textures, and may need more information about trap textures when trap shapes are nested via TrapShapeMerge. This function provides support for accessing texture information.

Overrides:

GetTextureValue in class TrapShape

Returns:

the texture value for the last point used (i.e. call GetTextureValue() after calling Iterate(), not before)
